ECX-1401 GTX1050

산업용보드 > 1U Rackmount

제품문의 02-3016-2464 http://www.wjubc.co.kr

Features

6-core 8th Gen Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake-S) w/ workstation-grade Intel® C246 chipset

2 DDR4 2666MHz memory, up to 64GB (ECC/Non-ECC)

NVIDIA® GeForce® GTX 1050 graphics engine, NVIDIA Pascal™ GPU architecture, up to 8K resolution

1 VGA, 1 HDMI, 2 DVI and 3 DisplayPort display interfaces, up to 6 independent HD displays

Multiple external USB 3.1 Gen 2, up to 10Gbps data transfer

6 independent GigE LAN with 4 IEEE 802.3at PoE+

32 Isolated DIO, 6 USB 3.1, 4 COM RS-232/422/485

Storage : 4 2.5" SSD trays, 1 CFast, 1 M.2, 4 SATA III

Expansion : 1 PCI, 2 Mini PCIe/mSATA, 1 M.2

3 external SIM sockets for WiFi/4G/3G/LTE/GPRS/UMTS

12V to 36V DC Power Input with 80V Surge Protection

Configurable Ignition Control

Specifications

System
Processor	6-core Intel® Xeon®/Core™ i7/i5/i3 processor (Coffee Lake-S)
Chipset	Intel® C246
BIOS	AMI
SIO	IT8786E
Memory	2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC)
I/O Interface
Serial	4 COM RS-232/422/485 (ESD 8KV)
USB	- 6 USB 3.1 (External) - 1 USB 2.0 (Internal)
Isolated DIO	32 Isolated DIO: 16 DI, 16 DO
LED	Power, HDD, PoE, Wireless
SIM Card	3 external SIM sockets
Expansion
Mini PCIe	2 Full-size for PCIe/USB/external SIM/mSATA
PCI/PCIe	1 PCI slot
M.2	1 M.2 Key E socket
Graphics
Graphics Processor	- Intel® UHD Graphics P630/630 - NVIDIA® GeForce® GTX 1050
Interface	- 1 VGA : Up to 1920 x 1200 @60Hz - 1 HDMI : Up to 4096 x 2304 @60Hz - 2 DVI : Up to 1920 x 1200 @60Hz - 1 DisplayPort : Up to 7680 x 3840 @60H - 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA	4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA	2 SATA III (Mini PCIe type, 6Gbps)
M.2	1 M.2 Key B socket
Storage Device	- 1 CFast socket, Push-in/Push-out ejector - 4 front-access 2.5" SSD/HDD trays
Audio
Audio Codec	Realtek ALC892, 5.1 Channel HD Audio
Audio Interface	1 Mic-in, 1 Line-out
Ethernet
LAN 1	Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2	Intel® I210 GigE LAN
PoE
LAN 3	GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4	GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5	GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6	GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Power Input	12V to 36V, DC-in
Power Interface	3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control	16 mode (Internal)
Remote Switch	3-pin Terminal Block
Surge Protection	Up to 80V/1ms Transient Power
Others
TPM	Optional Infineon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer	Reset : 1 to 255 sec./min. per step
Smart Management	Wake on LAN, PXE supported
HW Monitor	Monitoring temperature, voltages. Auto throttling control when CPU overheats.
Software Support
OS	Windows 10, Linux
Mechanical
Dimension	260mm x 215mm x 104.1mm (10.24" x 8.46" x 4.10")
Weight	5.8 kg (12.79 lb)
Mounting	- Wallmount by mounting bracket - DIN Rail mount (optional)
Environment
Operating Temperature	35W TDP CPU : -20°C to 60°C (-4°F to 140°F) 65W TDP CPU : -20°C to 55°C (-4°F to 131°F) 80W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Humidity	5% to 95% Humidity, non-condensing
Relative Humidity	95% at 60°C
Shock	- IEC 60068-2-27 - SSD : 50G @ wallmount, Half-sine, 11ms
Vibration	- IEC 60068-2-64 - SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC	CE, FCC, EN50155, EN50121-3-2
