| EC210-BT/Modular-Designed System, Intel Atom® E3800, DDR3L,1Expansion Slot,1 Mini PCIe,1 DVI-I,1 VGA | 산업용보드 > 1U Rackmount | 0 |
|---|---|---|
 Intel Atom® Processor E3800 Modular-Designed System Supports DDR3L SODIMM up to 8GB 2x 2.5" SATA drive bays 1 Vertical USB for securing data from unauthorized access (optional) 1 PCI expansion 15-Year CPU Life Cycle Support System Processor Intel® Atom™ E3845, Quad Core, 2M Cache, 1.91GHz, 10W 22nm Process Technology Memory Two 204-pin SODIMM up to 8GB Dual Channel DDR3L 1333MHz Graphics Controller Intel® HD Graphics Display 1 x DVI (DVI-D signal) 1 x VGA Supports 2 Independent Displays VGA: resolution up to 2560x1600 @ 60Hz DVI: resolution up to 1920x1080 @ 60Hz Dual Displays 1 x VGA + 1 x DVI Storage External/Internal 1 or 2 x 2.5" SATA 2.0 Drive Bay Standard: 1 single drive bay for 1 SATA drive Option: Single drive bay for second SATA drive Expansion Interface 1 x PCI 1 x Full-size Mini PCIe (PCIe/USB/SATA) Audio Audio Codec Realtek ALC888 High Definition Audio 2 watt, 4Ω Power Amplifier Ethernet Controller 2 x Intel® WGI210AT PCIe (10/100/1000Mbps) LED Indicators 1 x Power LED 1 x HDD LED 1 x Alert LED Front I/O Serial 4 x RS-232/422/485 (DB-9) USB 4 x USB 2.0 (type A) Buttons 1 x Power Button 1 x Reset Button Wi-Fi Antenna 2 x Wi-Fi Module Antenna Hole Rear I/O Ethernet 2 x GbE (RJ-45) Serial EC210-BTA881, EC210-BTAG60: 2 x RS-232 (DB-9) 4 x RS-232/422/485 (DB-9) EC210-BT6060: 2 x RS-232 (DB-9) USB EC210-BTA881: 1 x USB 3.0 (type A) 3 x USB 2.0 (type A) EC210-BTAG60, EC210-BT6060: 1 x USB 3.0 (type A) 1 x USB 2.0 (type A) DIO EC210-BTA881: 1 x 8-bit DIO (9-pole terminal block) EC210-BTAG60: 2 x 8-bit DIO (9-pole terminal block) Display EC210-BTA881: 1 x VGA (DB-15) 1 x DVI-I (DVI-D signal) EC210-BTAG60, EC210-BT6060: 1 x VGA (DB-15) Audio 1 x Speaker-out Buttons 1 x Reset Button Watchdog Timer Output & Interval System Reset, Programmable via Software from 1 to 255 Seconds Power Type Wide Range 9~36V DC-in Connector 3-Pole Terminal Block OS Support OS Support Windows 7, WES 7, Windows 8.1, WES 8 Linux (Distribution available upon request) Environment Operating Temperature 0°C ~ 55°C (SSD/mSATA) 0°C ~ 50°C (HDD) Storage Temperature -20°C ~ 85°C Mechanism Construction Aluminum + SGCC Mounting Wall/VESA mount Dimensions (W x H x D) 275mm x 94mm x 203mm (W x H x D) Weight 3.5 kg Standards and Certifications Shock Half Sine Wave 15G, 11ms, 3 Shock Per Axis Vibration IEC68-2-64 (HDD) Certifications CE, FCC Class A, RoHS Packing List Packing List 1 EC210 system unit 1 HDD drive bay kit: 2 Brackets, 1 SATA data/power cable, 4 Bracket screws, 4 HDD screws Terminal blocks 1 Quick Installation Guide 1 CD disk includes: Drivers / Manual
