| SPC150-BT / 5-Sides IP65 | 산업용보드 > FULL IP65/66패널PC | 0 |
|---|---|---|
|
제품문의 02-3016-2464 http://www.wjubc.co.kr
15" 1024x768 TFT LCD Panel with Touch Screen Intel® Celeron® Processor N2930 1x 2.5" SATA Drive Bay, 1 SD Socket 5 Sides IP65 Protection 9~36V DC Wide Voltage Power Input 15-Year CPU Life Cycle Support ? System Processor Intel® Celeron® Processor N2930, Quad Core, 2M Cache, 1.83GHz(2.16GHz),7.5W BGA 1170 packaging technology 22nm process technology Memory 2GB/4GB DDR3L Memory Onboard Single Channel DDR3L 1333MHz Display and Touch Screen Display 15" 1024x768 TFT LCD Panel with 5-wire Resistive Touch Screen Brightness 400 cd/m² Backlight Lifetime 50,000 MTBF LED Backlight Storage External/Internal 1 x 2.5" SATA 3.0 Drive Bay 1 x SD Socket Expansion Interface 1 x Full-size Mini PCIe (PCIe/USB) Audio Audio Codec Realtek ALC662 5.1-channel Ethernet Controller 2 x Intel® 82574L PCIe (10/100/1000Mbps) Bottom I/O Ethernet 2 x GbE (RJ-45) Serial 2 x RS-232/422/485 (RS232 and/or power) (DB-9) 2 x RS-232 (DB-9) USB 1 x USB 3.0 3 x USB 2.0 Audio 1 x Line-out Buttons 1 x 2-Pin Remote Power Switch 1 x Power Switch Power Type Wide Voltage 9~36V Connector 3-Pin Terminal Block OS Support OS Support Windows 7 Professional for Embedded System Windows 7 Ultimate for Embedded System Windows Embedded 8.1 Pro Windows Embedded 8.1 Industry Pro Environment Operating Temperature 0°C ~ 50°C Storage Temperature -30°C ~ 70°C Relative Humidity 10% ~ 90% @ 40°C (non-condensing) Mechanism Construction Stainless Steel Chassis IP Rating 5 Sides IP65 with I/O Cover Mounting VESA mount (VESA 75x75) Dimensions (W x H x D) 398mm x 316mm x 50.5mm (W x H x D) Weight 6.5 kg Standards and Certifications Shock Operating: IEC60068-2-67, 15G half sine w/o SSD Vibration Operating: IEC60068-2-64, 1G, 5~500Hz Certifications CE, FCC Class A, RoHS Packing List Packing List 1 SPC150-BT Touch Panel PC 1 Power Adapter Note: Please choose "SPC150-BT product page >Download button" to download the Driver and Manual.
