7” capacitive multi-touch with Gorilla glass 850 nits, Optical Bonding with AR/AF sunlight readable solution IP65, MIL-STD-810G, 5-foot drop resistance NFC, GNSS, WLAN, WWAN, Bluetooth Hot swappable battery design Optional fingerprint and MRZ reader ? System Processor Intel® Celeron N2930 Processor 1.83GHz Memory 4GB/8GB DDR3L Onboard Display and Touch Screen Display 7" WSVGA (1024 x 600), Multiple Capacitive Touch with Gorilla Glass Sensor Accelerometer Sensor E-Compass Sensor Gyroscope Sensor Vibrator Light Sensor Brightness 850 cd/m², Optical Bonding with AR/AF Solution Storage External/Internal 128GB/256GB SSD Onboard FIPS 140-2 Certified SSD Onboard up to 256GB (optional) Audio Internal 2 x 0.8W Speaker LED Indicators 1 x Red/Green LED for Power and System Status 1 x Blue LED for NFC RFID I/O External 1 x microSD 1 x micro SIM 1 x Earphone & Mic 2 x USB 3.0 Type A 1 x RJ-232 1 x Docking Connector (32-pin) 1 x DC Jack 2D Barcode Reader + MSR 2-in-1 Module (optional) MRZ Reader+ MSR 2-in-1 Module (optional) Buttons 1 x Power Button 1 x Menu Button 1 x Windows Button 4 x Programmable Button Communication Wireless Wi-Fi 802.11 a/b/g/n/ac Bluetooth V4.0+EDR NFC RFID 13.56MHz (ISO 14443 A/B, FeliCa) GNSS (GPS/GLONASS, optional BeiDou) 4G LTE (optional) Camera Rear Camera 8.0 Mega Pixels, Auto Focus, LED Flash Light Front Camera 2.0 Mega Pixels Security TPM TPM 2.0 Fingerprint Reader, Capacitive, 508 dpi (optional) Janus USB Ignition Key, Phoenix SecureWipe (optional) Power Type 100~240V AC 50/60Hz 0.8A Battery 2900mAh (standard) 4200mAh (optional Hot Swappable Battery) OS Support OS Support Windows 10 loT Enterprise Window Embedded 8.1 Industry Pro Environment Operating Temperature -20 to 50°C Storage Temperature -30 to 70°C Charging Temperature 0 to 40°C Relative Humidity 5 to 95% RH (non-condensing) Mechanism Dimensions 225mm x 168mm x 270mm (8.9" x 6.6" x 1.1") IP Rating IP65 Protection Weight 950 g Standards and Certifications Drop 5ft Drop Tested Certifications CE, FCC, MIL-STD-810G Packing List Packing List 1 RPC070-BT Tablet 1 Power Adapter 1 Hand Strap 1 Shoulder Strap 1 Handle Note: Please choose "RPC070-BT product page >Download button" to download the Driver and Manual.
