| RPC101-BT | 산업용보드 > FULL IP65/66패널PC | 0 |
|---|---|---|
|
제품문의 02-3016-2464 http://www.wjubc.co.kr IP65, MIL-STD-810G, 5-foot drop resistance 1000 nits sunlight readable display Capacitive touch supports glove touch, 2mm hard tip stylus; digitizer by request GNSS, Wi-Fi, Bluetooth and optional 4G LTE Hot swappable battery design Optional fingerprint and MRZ reader ? System Processor Intel Atom® E3827 Processor 1.75GHz Memory 4GB/8GB DDR3L Onboard Display and Touch Screen Display 10.1" WUXGA (1920 x 1200) TFT LCD, Multiple Capacitive Touch with Gorilla Glass Sensor Accelerometer Sensor E-Compass Sensor Gyroscope Sensor Vibrator Light Sensor Brightness 1000 cd/m² Storage External/Internal 128GB/256GB mSATA SSD 32GB mSATA SSD (support Android OS only) Audio Internal 2 x 0.8W Speaker LED Indicators 1 x Red/Green LED for Power and System Status 1 x Blue LED for NFC RFID I/O External 1 x microSD 1 x micro SIM 1 x micro HDMI 1 x Earphone & Mic 1 x USB 2.0 Type A 1 x USB 3.0 Type A 1 x RJ-232 1 x GbE (RJ-45) 2 x RF Pass-through Connector for WLAN/ GNSS/ WWAN 1 x Docking Connector (12-pin) 1 x DC Jack NFC + Smart Card Reader 2-in-1 Module (optional) Built-in 2D Barcode Reader (optional) Buttons 1 x Power Button 1 x Home Button 1 x Volume Button 1 x Barcode Trigger 3 x Programmable Button Communication Wireless Wi-Fi 802.11 a/b/g/n/ac Bluetooth V4.0+EDR GNSS (GPS/GLONASS, BeiDou) 4G LTE (optional) NFC RFID 13.56MHz (optional) Camera Rear Camera 5.0 Mega Pixels, Auto Focus, LED Flash Light Front Camera 2.0 Mega Pixels Security TPM TPM 1.2 Janus USB Ignition Key, Phoenix SecureWipe (optional) Power Type 100~240V AC 50/60Hz 0.8A Battery 4500mAh (standard Hot Swappable Battery) 9000mAh (optional Hot Swappable Battery) OS Support OS Support Windows 7 Windows 10 loT Enterprise Android 5.1 (optional) Environment Operating Temperature -20 to 50°C Storage Temperature -30 to 70°C Charging Temperature 0 to 40°C Relative Humidity 5 to 95% RH (non-condensing) Mechanism IP Rating IP65 Protection Dimensions (W x H x D) 280mm x 195mm x 230mm (11" x 7.7" x 0.9") Weight 1330 g Standards and Certifications Drop 5ft Drop Tested Certifications CE, FCC, MIL-STD-810G Packing List Packing List 1 RPC101-BT Tablet 1 Power Adapter 1 Hand Strap 1 Shoulder Strap 1 Handle 1 Stylus Note: Please choose "RPC101-BT product page >Download button" to download the Driver and Manual.
