JNF832-3455

산업용보드 > EATX

- Intel Apollo Lake Celeron J3455 Processors, 10W

- Embedded Long-life 3.5" SBC Series, Planned Lifecycle Through Q3’2031

- Supports up to 3 display, 2HDMI and eDP

- Gigabit LAN, 2 * M.2, 1 * Full size Mini PCI-E

- Built-in +12V Power Jack, SIM Slot, RS232

- ECO-design for EuP/ErP

Specification

Model Name	NF832
Part Number	JNF832-3455
Form Factor	3.5" SBC (148 x 102mm)
Processor	Intel® Celeron J3455 Processor Quad Core 1.50 GHz - 2.30 GHz, 10W TDP * Ships with silver flat heatsink for bench testing
Memory	1 x 204-pin DDR3L-1866 SO-DIMM up to 8GB (1.35V required)
Graphics	Intel HD Graphics 500, 250MHz - 750MHz (J3455)
Audio	Realtek ALC662 HD Audio Codec
LAN	1 x Realtek RTL8111H PCI-E Gigabit LAN
Storage	1 x SATA3 6Gb/s Connector 1 x M.2 SATA M-key 2242/2280 length
Super IO	FINTEK F81962D
TPM	Intel fTPM 2.0 (PTT) Trusted Computing Firmware OEM Option: Onboard TPM v1.2 or v2.0
