JNF831-2930

산업용보드 > EATX

- Intel Celeron N2930 SoC Processor

- Embedded Long-life 3.5" SBC Series, Planned Lifecycle Through Q1’2029

- Supports 2 Display, VGA and HDMI or eDP

- Gigabit LAN, 2 * M.2, 1 * Full size Mini PCI-E

- Built-in +12V Power Jack, SIM, and RS232

- ECO-design for EuP/ErP

Specification

Model Name	NF831
Part Number	JNF831-2930
Form Factor	3.5" SBC (148 x 102mm)
Processor	Intel® Celeron N2930 SoC, 1.83GHz ? 2.16GHz Burst, Quad-Core, 7.5W TDP/4.5W SDP * Ships with silver flat heatsink for direct attaching to a surface
Memory	1 x 204-pin DDR3L-1333 SO-DIMM up to 8GB (1.35V required)
Graphics	Intel HD Graphics, 313MHz - 854MHz
Audio	Realtek ALC662 HD Audio Codec
LAN	1 x Realtek RTL8111H PCI-E Gigabit LAN
Storage	1 x SATA2 3Gb/s Connector 1 x M.2 SATA M-key 2242/2280 length
Super IO	FINTEK F81804U
TPM	Intel fTPM 2.0 (PTT) Trusted Computing Firmware OEM Option: Onboard TPM v1.2 or v2.0
